Super Port TTL UART to Ethernet Module Lan port module
![]() Click to enlarge |
|
Item |
Parameter |
Value |
Hardware |
Work Voltage |
DC 3.0~3.6 V,(3.3V best choice) |
Work Current |
130mA@3.3V |
|
Ethernet |
RJ45、10/100Mbps; Auto switch between cross and direct connection |
|
Package type |
Pin-in package |
|
Baud Rate |
600~1M(bps) |
|
Software |
Network Protocol |
IP、TCP、UDP、DHCP、DNS、HTTP、ARP、ICMP、Web socket |
IP |
Static IP or DHCP |
|
DNS |
Supports |
|
Configure |
Setup software, Web-page configuration, AT command |
|
Work Modem |
TCP Server/TCP Client/UDP Server/UDP Client |
|
Modbus |
Modbus Gateway: Modbus RTU to TCP, Modbus Polling |
|
Web to Serial |
Web socket: Web to serial |
|
Httpd Client |
Supports |
|
Class RFC2217 |
Supports |
|
Customized Webpage |
Supports |
|
Web Cache |
Send:16Kbyte;Receive:16Kbyte; |
|
Serial Port Cache |
Send:2Kbyte;Receive:2Kbyte; |
|
Average latency |
On Lan , the time<10ms |
|
Software |
Setup Software, Virtual COM software |
|
Others |
Certificate |
/ |
Protection |
1.5KV Electromagnetic isolation |
|
Size |
35.0x19.39x18.25 mm(L*W*H) |
|
Work Temp |
-40~85℃ |
|
Storage Temp |
-40~105℃ |
|
Work Humidity |
5%~95% RH |
|
Storage Humidity |
5%~95% RH |
User Manual
[User manual] USR-K7-user-mannual-V1.0.1 | download
[User Guide] USR-K7-User-Guide | download
[AT commands] USR-K7-AT-Commands | download
[Datasheet] USR-K7-Datasheet | download
[Hardware Manual] USR-K7-Hardware-Manual-V1.0.0 | download
[User Manual] Difference-between-K7-K6-and-USR-K3-K2-version | download
[User Manual] Setting-Agreement | download
PCB Library
[PCB Library] USR-Kx-PCB-Library-AD-Version | download
Application Software
[USR-VCOM] USR-VCOM_V3.7.2.527_Setup | download
[USR-TCP-Test] Testing Software | download
[USR-TCP-Test_android] Testing Software | download
[USR-M4] USR-M4 Setup Software V2.3.4.102 | download
Product Certificate
[CE Certificates] CE-Certificates | download
[FCC Certificates] FCC-Certificates | download
[Certificate] 2019-USR-TCP232-ED2ROHS2.0 | download
